4MFSGTV Series
Forged gate valve
Size Range : 2″ to 12″
Description
Forged Gate Valve Manufacturer
4Matic forged steel gate valves are offered in solid wedge, bolted bonnet and welded bonnet design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials. 4Matic forged steel gate valves are manufactured according to API 602 Design.
- Class : 800 to Class 2500
- Materials : Available in Forged (A105, LF2, F5, F11, F22, A182 F304 (L), F316 (L), F347, F321, F51), Alloy 20, Monel, Inconel, Hastelloy
Design Features
- SW, NPT, RF, or BW
- Outside Screw & Yoke (OS&Y)
- Bolted Bonnet, Welded Bonnet or Pressure Seal Bonnet
Technical Specification
Design Standard
- Design & manufacture according to API 602, ASME B16.34
- End Connection according to ASME B16.11 (SW), ASME B1.20.1 (NPT), ASME B16.5 (RF, RTJ)
- Test & inspection according to API 598
- Also available per NACE MR-0175, NACE MR-0103, ISO 15848, API 624
